Main use
This machine is mainly used for lubricating oil and grease extreme pressure and anti abrasion performance of the simulation evaluation, can also be used to study the performance of aviation research and a variety of antiwear coatings, kerosene coating, metal and nonmetal materials.
Main technical specifications and parameters
The maximum test force: 5000N
The spindle speed range: 100~1500r/min adjustable
The test force lever ratio: 10:1
The friction bar scale: 0.5N/100mm
The test oil temperature range: room temperature ~100 C
The test force acceleration: 8.92~13.33N/ s
The standard test ring size: 49.22mmx13.06mm diameter
The standard block size: 13.32mmx19.05mm
The test machine size (length x width x height) mm
The host: 1140mmx660mmx1620mm
The force application device: 460mmx460mmx900mm
